Temperature Range-65 ~ 165°C (PE Cable -40 ~ 85°C)
Vibration MIL-STD-202,Method 213
The Characteristic Impedance of 50Ω
Frequency Range DC ~ 12.4GHz (Semi-Rigid Cable 0~18GHz)
Operating Voltage 335v Max (Effective Value)
Pressure Resistance 1000V RMS (Minimum Sea Level)
Contact Electronic Resistance
The Inner Conductor between ≤ 3 M Ω
Return Conductor between ≤ 2 MΩ
Insulating Electronic Resistance ≥ 5000 MΩ
Insertion Loss ≤ 0.15 DB/6GHz
Voltage Standing Wave Ratio Direct Flexible Cable ≤ 1.10 0.002f
Semi-Rigid Cable ≤ 1.05 0.001f
Curved Flexible Cable ≤ 1.20 0.003f
Semi-Rigid Cable ≤ 1.10 0.001f
Durability ≥ 500 Times (Cycles)
Shell Brass Plated Hard Gold
Pin Brass Plated Hard Gold
Wooden Bronze Plated Hard Gold
Elastic Contact Metal Plated with Shell Bronze
Insulator Polytetrafluoroethylene
Compression Joint Sleeve Copper Alloy Nickel Plated Or Gold Plated
O-Type Seal Silicon Rubber 6146
